Product Description:

This product is a high-performance USB AF3.0 female connector featuring a four-pin SMT board-mounted design with a 90-degree angle bevel. It is suitable

for various electronic device connection needs, offering excellent electrical performance and stability. It is designed for efficient installation on automated

production lines.

Key Features:

1. USB AF3.0 Standard:

   Conforms to USB AF3.0 standards, supporting data transmission speeds up to 5Gbps, meeting most data connection requirements.

2. Four-Pin SMT Design:

   The four-pin SMT design enhances connection stability and reliability, suitable for high-efficiency automated production.

3. 90-degree Bevel Installation:

   The 90-degree bevel design optimizes installation space and cable management, aiding in space-saving and streamlined cabling.

4. Board Mounted Installation:

   The board-mounted installation simplifies the installation process and increases installation efficiency.

5. High Reliability:

   Made from high-quality materials, ensuring stability and durability over the long term.

Compliance Statement:

This product strictly adheres to international and industry certification standards, ensuring its compliance with safety and environmental regulations:

1. ISO 9001 Quality Management System Certification:

   Ensures that the product meets international quality management standards during design and production.

2. REACH Certification:

   Complies with the EU chemicals registration, evaluation, authorization, and restriction regulations, ensuring the materials are safe and environmentally

friendly.

3. RoHS Certification:

   Complies with the EU Restriction of Hazardous Substances (RoHS) directive, ensuring the product is free from harmful substances and promotes user

health.

Contact Information:

- Hotline: 13310802726

- Email: mc13310802726@163.com

- Address: Dalingshan Town, Dongguan City, Guangdong Province

If you have any questions or need further information, feel free to contact us, and we will provide professional support.

USB AF3.0 Board Mounted Four-Pin SMT 90 Degree L=14.25 Edge Bent Usage Notes:

1. Installation and Soldering:

   - Ensure the soldering area is clean and free from oil or dust to maintain soldering quality.

   - Soldering temperature should be controlled within the recommended range to avoid damaging internal components.

   - The PCB mounting should ensure proper alignment and be firmly soldered to prevent loosening during use.

2. Electrical Performance:

   - This product is designed for USB 3.0 high-speed data transmission requirements, supporting up to 5Gbps data transfer rates.

   - The edge bent design enhances anti-interference capabilities and improves signal stability.

3. Insertion and Extraction:

   - Handle insertion and extraction gently to avoid damaging the pin header.

   - Ensure proper alignment of the pin header with the interface to prevent misalignment or damage during insertion.

4. Material Properties:

   - The housing is made from durable plastic material that offers good impact resistance and wear resistance.

   - The contact points are made from high-conductivity materials, providing stable electrical connections.

5. Operating Environment:

   - This product is suitable for consumer electronics, industrial equipment, and other high-performance data transmission applications.

   - Avoid long-term use in high-humidity, high-temperature, or corrosive environments to maintain stable performance.

6. Storage Conditions:

   - Store unused products in a dry, ventilated environment away from direct sunlight.

   - Avoid storing in extreme temperature conditions to prevent material aging or performance degradation.

For more product information or technical support, please contact us:

- Hotline: 13310802726

- Email: mc13310802726@163.com
