Product Description:

This product is a high-performance AF2.0 waterproof USB female connector featuring a vertical insert design with no ears and a post design, ensuring high

stability and reliability for demanding applications. It offers excellent waterproof performance and a stable connection, suitable for a wide range of industrial

and outdoor electronic devices.

Key Features:

1. AF2.0 Standard:

   Complies with the AF2.0 standard, supporting data transmission speeds up to 480Mbps, meeting most device connection needs.

2. Waterproof Design:

   No ears design and black plastic material effectively prevent interface damage due to ear stress and further enhance waterproof performance.

3. Vertical Insert Installation:

   Vertical insert design simplifies the installation process, suitable for automated production and efficient installation.

4. Post Design:

   Post design provides stable connections and better shock resistance, suitable for harsh environments.

5. High Reliability:

   Made from high-quality materials, ensuring stability and durability over the long term.

Compliance Statement:

This product strictly adheres to international and industry certification standards, ensuring its compliance with safety and environmental regulations:

1. ISO 9001 Quality Management System Certification:

   Ensures that the product meets international quality management standards during design and production.

2. REACH Certification:

   Complies with the EU chemicals registration, evaluation, authorization, and restriction regulations, ensuring the materials are safe and environmentally

friendly.

3. RoHS Certification:

   Complies with the EU Restriction of Hazardous Substances (RoHS) directive, ensuring the product is free from harmful substances and promotes user

health.

Contact Information:

- Hotline: 13310802726

- Email: mc13310802726@163.com

- Address: Dalingshan Town, Dongguan City, Guangdong Province

If you have any questions or need further information, feel free to contact us, and we will provide professional support.

AF2.0 Waterproof Female Connector Vertical Plug L=11.3 No Ears, With Posts, Black Plastic USB Interface Usage Notes:

1. Installation and Soldering:

   - Ensure the soldering area is clean and free of oil or dust to maintain the quality of the weld.

   - The soldering temperature should be within the recommended range to avoid damaging internal components.

   - Ensure the socket is securely installed to prevent loosening during plugging and unplugging.

2. Electrical Performance:

   - This product features a waterproof design, making it suitable for high-humidity environments and providing good water resistance and corrosion

resistance.

   - Supports high-speed data transmission and stable power output.

3. Insertion and Extraction:

   - Handle insertion and extraction gently to avoid damaging the socket.

   - Ensure proper alignment of the plug with the socket to prevent misalignment or damage during insertion.

4. Material Properties:

   - The connector housing is made of black high-strength plastic, which is wear-resistant and corrosion-resistant.

   - Contact points are made of high-conductivity materials to provide stable electrical connections.

5. Waterproof Performance:

   - The product design complies with IP68 waterproof rating, making it suitable for use in various wet and harsh environments.

   - Ensure the interface is fully sealed to prevent water ingress that could affect performance.

6. Cleaning and Maintenance:

   - If dirt or dust accumulates on the interface, clean it with a soft, dry cloth. Avoid using corrosive cleaning agents.

   - Regularly inspect the contact points and solder joints to ensure no loosening or oxidation occurs.

7. Operating Environment:

   - This product is suitable for automotive, industrial equipment, and other waterproof application scenarios.

   - Avoid long-term use in high-temperature or highly corrosive environments to maintain stable performance.

8. Storage Conditions:

   - Store unused products in a dry, ventilated environment away from direct sunlight.

   - Avoid storing in extreme temperature conditions to prevent material aging or performance degradation.
