Product Description:

This Type-C male connector features a 24Pin interface with a vertical mount design, a length of 11.1mm, and a three-leg riveted structure, providing a

reliable connection solution for USB devices. The product is widely used in various electronic devices, supporting efficient data transmission and power

connection. The riveted design enhances connection stability and durability, making it suitable for various automated production lines and devices.

Key Features:

1. 24Pin Interface:

   The 24Pin design ensures stable data transmission and power connection, making it compatible with various USB devices.

2. Vertical Mount Design:

   The vertical SMT (Surface-Mount Technology) design ensures stable connections, easy automated production, and installation, improving work efficiency.

3. Three-Leg Riveted Structure:

   The three-leg riveted design enhances mechanical stability and improves connection durability and reliability, ensuring long-term performance in harsh

environments.

4. Efficient Data Transmission:

   Supports high-speed data transmission according to USB standards, meeting the data transmission rate requirements of modern electronic devices.

5. Wide Application:

   Suitable for consumer electronics, industrial devices, automotive electronics, and other fields, supporting connection for various USB devices.

Compliance Statement:

This product strictly adheres to international and industry certification standards, ensuring its compliance with safety and environmental regulations:

1. ISO 9001 Quality Management System Certification:

   Ensures the product meets international quality management standards during design and production.

2. REACH Certification:

   Complies with the EU chemicals registration, evaluation, authorization, and restriction regulations, ensuring materials are safe and environmentally friendly.

3. RoHS Certification:

   Complies with the EU Restriction of Hazardous Substances (RoHS) directive, ensuring the product is free from harmful substances and promotes user health.

Contact Information:

- Hotline: 13310802726

- Email: mc13310802726@163.com

- Address: Dalingshan Town, Dongguan City, Guangdong Province

If you have any questions or need further information, feel free to contact us, and we will provide professional support.

Type-C Male Connector 24Pin Vertical L=11.1 Three-Leg Vertical Riveted USB Interface Usage Notes:

1. Installation and Soldering:

   - Ensure the soldering area is clean and free from contaminants before starting the soldering process.

   - Use appropriate soldering equipment and temperature to avoid overheating and damaging components.

   - Align the vertical pins with the PCB pads and check the solder joints for firm and stable connections after installation.

2. Electrical Performance:

   - Supports high-speed data transmission, fully compliant with USB interface standards, suitable for connecting various electronic devices.

   - Pins are made with high-conductivity materials, ensuring low contact resistance and stable electrical performance for long-term reliability.

3. Insertion and Extraction:

   - Avoid excessive force when inserting or extracting the connector. Handle gently to prevent damage to the pins or connector.

   - Ensure the correct orientation when inserting the connector to prevent poor contact or mechanical damage.

4. Rivet Design:

   - The rivet design enhances the connector's stability, ensuring that it remains securely connected over long periods of use.

   - During installation, ensure the riveted part is fully engaged with the connector to avoid looseness or poor contact.

5. Materials and Design:

   - Made from stainless steel or high-strength alloy materials, providing corrosion resistance and oxidation protection, suitable for harsh environmental

conditions.

   - Precision-designed vertical pins and protective structure ensure product stability in various environments.

6. Application Scenarios:

   - Suitable for consumer electronics, industrial devices, automotive electronics, and other fields requiring stable connections.

   - Particularly suitable for devices requiring robust connections or frequent insertion and extraction.

7. Storage and Transportation:

   - Store in a dry, cool, and well-ventilated environment, avoiding direct sunlight and humidity.

   - During transportation, avoid strong impacts to prevent damage to the rivet or pin components.
