Product Description:

This waterproof Type-C USB female connector features a 16Pin interface with a vertical mount design and a length of 7.85mm. It is designed for applications

that require high protection. With waterproof capability, this connector ensures reliable performance in harsh environments. It is widely used in consumer

electronics, industrial devices, automotive electronics, and more, supporting data transmission and power connection via USB interfaces.

Key Features:

1. Waterproof Design:

   This Type-C female connector has an IPX7 waterproof rating, preventing moisture from entering, ensuring reliable performance in humid or outdoor

environments.

2. 16Pin Interface:

   The 16Pin design provides stable signal transmission and power connection, supporting USB data and power transfer, and meeting the needs of various

devices.

3. Vertical Mount Design:

   The vertical SMT (Surface-Mount Technology) design allows for automated production and efficient installation while providing better connection stability.

4. High Durability:

   Made with high-quality materials, it has excellent corrosion resistance and durability, ensuring stable performance over extended use.

5. Compact Size:

   The compact design makes it suitable for devices with limited space, and it is easy to install. It is widely used in mobile devices, industrial equipment,

automotive electronics, etc.

Compliance Statement:

This product strictly adheres to international and industry certification standards, ensuring its compliance with safety and environmental regulations:

1. ISO 9001 Quality Management System Certification:

   Ensures the product meets international quality management standards during design and production.

2. REACH Certification:

   Complies with the EU chemicals registration, evaluation, authorization, and restriction regulations, ensuring materials are safe and environmentally friendly.

3. RoHS Certification:

   Complies with the EU Restriction of Hazardous Substances (RoHS) directive, ensuring the product is free from harmful substances and promotes user health.

Contact Information:

- Hotline: 13310802726

- Email: mc13310802726@163.com

- Address: Dalingshan Town, Dongguan City, Guangdong Province

If you have any questions or need further information, feel free to contact us, and we will provide professional support.

Waterproof Type-C Female Connector 16Pin Vertical L=7.85 USB Interface Usage Notes:

1. Installation and Soldering:

   - Ensure the soldering area is clean and free from contaminants before starting the soldering process.

   - Use recommended soldering temperature to avoid overheating and damaging components.

   - For the vertical design, ensure pins align with the PCB pads, and verify that each pin is securely soldered.

2. Waterproof Performance:

   - This product has excellent waterproof capabilities, suitable for humid environments or occasional exposure to water.

   - During installation, ensure that the waterproof structure remains intact to prevent water ingress.

   - It is recommended to conduct waterproof testing before long-term use to ensure compliance with IP standards.

3. Electrical Performance:

   - Supports high-speed data transmission, fully compliant with USB interface standards, ideal for various electronic devices.

   - High-conductivity materials ensure low contact resistance, providing stable electrical performance and long-term reliability.

4. Insertion and Extraction:

   - Apply moderate force when inserting or extracting to avoid damaging the connector or pins.

   - Ensure the connector is inserted in the correct orientation to avoid poor contact or mechanical damage.

5. Materials and Design:

   - The housing is made of corrosion-resistant stainless steel, providing excellent oxidation protection and reliability for long-term use.

   - The precision design of the waterproof structure and pins ensures stability and durability in harsh environments.

6. Application Scenarios:

   - Suitable for consumer electronics, industrial devices, and outdoor electronic equipment that require waterproof protection.

   - For use in high-humidity, high-temperature, or corrosive environments, regular inspection is recommended.

7. Storage and Transportation:

   - Store in a dry, cool, and well-ventilated environment, away from direct sunlight and high humidity.

   - During transportation, avoid strong impacts that may damage the waterproof structure and pins.

For more information, please contact us:

- Hotline: 13310802726

- Email: mc13310802726@163.com
