Product Description:

This waterproof Type-C USB female connector features a 6Pin interface with a recessed depth of 0.55mm and four-leg mounting, specifically designed for

devices requiring high protection performance. It is ideal for use in various environments and widely applicable in consumer electronics, outdoor equipment,

and industrial applications, providing excellent durability and waterproof capability.

Key Features:

1. Waterproof Design:

   Offers superior waterproof performance, suitable for underwater or humid environments, ensuring stable operation of devices.

2. 6Pin Interface:

   Uses a 6Pin interface to support data transmission and power connections, suitable for common USB devices.

3. Recessed 0.55mm Design:

   Ensures stable mechanical and electrical performance, enhancing connection reliability.

4. Four-Leg Mount Structure:

   Provides better stability and support, ensuring durability and reliability in various applications.

5. Wide Application:

   Compact design makes it suitable for portable devices, industrial applications, and embedded devices.

Compliance Statement:

This product strictly adheres to international and industry certification standards, ensuring its compliance with safety and environmental regulations:

1. ISO 9001 Quality Management System Certification:

   Ensures the product meets international quality management standards during design and production.

2. REACH Certification:

   Complies with the EU chemicals registration, evaluation, authorization, and restriction regulations, ensuring materials are safe and environmentally friendly.

3. RoHS Certification:

   Complies with the EU Restriction of Hazardous Substances (RoHS) directive, ensuring the product is free from harmful substances and promotes user health.

Contact Information:

- Hotline: 13310802726

- Email: mc13310802726@163.com

- Address: Dalingshan Town, Dongguan City, Guangdong Province

If you have any questions or need further information, feel free to contact us, and we will provide professional support.

Waterproof Type-C Female Connector 6Pin Recessed 0.55mm Four-Leg Plug-in USB Interface Usage Notes:

1. Installation and Soldering:

   - Ensure the soldering area is clean and free from contaminants to improve soldering quality.

   - Use recommended soldering equipment within the recommended temperature range to avoid overheating and damage.

   - For the recessed design, ensure the pins align with the PCB pads, and check the soldering for secure connections after installation.

2. Waterproof Performance:

   - This product provides basic waterproof capabilities, suitable for humid environments or occasional water exposure.

   - Ensure the waterproof structure is intact during installation to prevent liquid ingress affecting performance.

   - Conduct waterproof testing in harsh environments to ensure the product meets the required protection standards.

3. Electrical Performance:

   - Supports standard data transmission functions, fully compliant with USB interface standards, suitable for various electronic devices.

   - Uses high-quality conductive materials to ensure reliable electrical performance and stable contact resistance.

4. Insertion and Extraction:

   - Handle the connector gently during insertion and extraction to avoid damage or poor contact.

   - Ensure the connector is inserted in the correct orientation to prevent mechanical damage or improper electrical connections.

5. Materials and Design:

   - The housing is made from durable stainless steel with excellent corrosion resistance and oxidation protection.

   - Precisely designed pins and waterproof components ensure stable and long-lasting performance under prolonged use.

6. Application Scenarios:

   - Suitable for use in consumer electronics, industrial devices, and outdoor electronics, especially in applications requiring waterproof protection.

   - Avoid prolonged use in extreme environments such as high-temperature, high-humidity, or corrosive atmospheres.

7. Storage and Transportation:

   - Store in a dry, cool, and well-ventilated area, away from direct sunlight and high humidity.

   - During transportation, avoid strong impacts that could damage the waterproof components or pins.
