Product Description:

This product is a high-performance waterproof Type-C USB female connector with a 24Pin surface-mount design, meeting the IPX8 waterproof standard.

Specifically designed for harsh environments, it offers exceptional durability and reliability, making it ideal for consumer electronics, industrial equipment,

outdoor devices, and other applications requiring a high waterproof rating.

Key Features:

1. IPX8 Waterproof Performance:

   Meets the IPX8 standard, ensuring reliability during prolonged underwater operation in extreme conditions.

2. 24Pin Interface:

   Supports high-speed data transmission and high-power delivery, catering to diverse application requirements.

3. Surface-Mount Design:

   Surface-mount structure facilitates automated production and provides stable electrical connections.

4. Durable and Reliable:

   Made of premium materials and advanced craftsmanship, ensuring excellent resistance to corrosion and mechanical stress.

5. Compact Design:

   The compact form factor saves space, suitable for installation in various compact devices.

Compliance Statement:

This product strictly adheres to international and industry certification standards, ensuring its compliance with safety and environmental regulations:

1. ISO 9001 Quality Management System Certification:

   Ensures the product meets international quality management standards during design and production.

2. REACH Certification:

   Complies with the EU chemicals registration, evaluation, authorization, and restriction regulations, ensuring the materials are safe and environmentally

friendly.

3. RoHS Certification:

   Complies with the EU Restriction of Hazardous Substances (RoHS) directive, ensuring the product is free from harmful substances and promotes user

health.

Contact Information:

- Hotline: 13310802726

- Email: mc13310802726@163.com

- Address: Dalingshan Town, Dongguan City, Guangdong Province

If you have any questions or need further information, feel free to contact us, and we will provide professional support.

Waterproof Type-C Female Connector 24Pin Vertical L=8.8 IPX8 USB Interface Usage Notes:

1. Installation and Soldering:

   - Ensure the soldering area is clean and free of contaminants to maintain soldering quality.

   - Use recommended soldering equipment to achieve uniform solder points and avoid overheating.

   - Align the vertical pins precisely with the PCB pads and verify a secure connection after soldering.

2. Waterproof Performance:

   - Compliant with IPX8 waterproof standards, suitable for demanding underwater applications.

   - Ensure the waterproof structure is intact during installation to prevent liquid ingress.

   - Perform waterproof tests before long-term use to confirm the product meets the required performance.

3. Electrical Performance:

   - Supports high-speed data transfer and high-current charging, fully compliant with USB standards.

   - High-conductivity materials ensure low contact resistance and stable electrical performance.

4. Insertion and Extraction:

   - Apply moderate force during insertion and removal to avoid damaging the connector.

   - Ensure correct orientation during insertion to prevent misalignment or mechanical damage.

5. Materials and Design:

   - Stainless steel housing provides excellent corrosion resistance and durability.

   - Precision design integrates waterproof components with electrical performance for long-term stability.

6. Application Scenarios:

   - Widely used in waterproof applications for consumer electronics, industrial devices, and outdoor equipment.

   - Regularly inspect the product when used in high-temperature, high-humidity, or corrosive environments.

7. Storage and Transportation:

   - Store in a dry and ventilated environment, avoiding direct sunlight and high humidity.

   - Avoid strong impacts during transportation to maintain the integrity of waterproof components and pins.

For more information, please contact us:

- Hotline: 13310802726

- Email: mc13310802726@163.com
