Interface and transmission compliance: Fully compliant with the USB3.2 Gen2 and PD 3.0 specifications released by the USB Implementers Forum (USB-IF), passing USB-IF compatibility testing to ensure compatibility with various TYPE C male connectors, fast charging adapters, and digital devices, avoiding transmission interruptions, fast charging failures, and other issues, and adapting to multi scenario transmission needs.
Environmental compliance: Strictly following the EU RoHS 3.0 (2015/863/EU) directive and the Chinese GB/T 26572-2011 standard, all raw materials such as high conductivity copper, 304 stainless steel, LCP black glue, etc. are free of 10 restricted harmful substances such as lead and mercury. They have passed third-party environmental testing such as SGS and TUV, and can provide compliance reports to adapt to the global environmental strict market.
Electrical safety compliance: Complies with IEC 62368-1 electrical safety standards, with insulation resistance ≥ 1000M Ω (500V DC) and withstand voltage ≥ 500V AC (no breakdown or arcing for 1 minute), effectively preventing short-circuit leakage risks; Simultaneously meet the requirements of FCC Part 15 Class B electromagnetic compatibility in the United States, with an electromagnetic radiation level of ≤ 54dB μ V/m (30MHz-1GHz), avoiding interference with surrounding Bluetooth, Wi Fi and other components.
Production quality compliance: The production process follows the ISO 9001 quality management system and undergoes full process testing from raw material procurement to finished product delivery. Raw materials need to provide a certificate of conformity. During production, samples are taken every hour to test indicators such as pin gold plating thickness and spring elasticity. The finished product passes 100% conductivity and appearance testing, with a failure rate controlled below 0.1%. Batch quality reports can be provided.


For more information, please contact us:

- Hotline: +86 13310802726

- Email: mc13310802726@163.com

Storage and transportation precautions: Store in a dry and clean environment with a temperature range of -5 ℃~35 ℃ and a relative humidity of 25%~55%. Keep away from high temperature and humidity, direct sunlight, and corrosive gases to prevent oxidation of the high conductivity copper gold plating layer and aging of the LCP black adhesive; Transport with anti-static shielding bag+turnover box packaging, built-in moisture-proof agent, labeled "Handle with care" to avoid deformation of the shell and damage to the shrapnel; Unused products must be resealed within 24 hours after opening.
Installation precautions: Before installation, confirm that the PCB board pads are matched with the pins, with a pad error of ≤± 0.05mm; for reflow soldering, strict control of parameters is required, with a preheating section of 90 ℃~120 ℃ (60-90 seconds) and a peak section of 250 ℃~260 ℃ (≤ 8 seconds), to avoid deformation of LCP black glue caused by high temperature; After installation, AOI inspection is carried out to ensure that the mother seat is not tilted, the pins are not soldered, the spring pieces are not stuck, and any abnormal products need to be repaired with professional tools.
Precautions for use and maintenance: When using, the input current should not exceed 3A rated value to avoid pin overheating caused by overload; The insertion and removal of the male head should be carried out vertically and smoothly. Although the contact is enhanced by shrapnel, excessive tilting during insertion and removal will wear out the shrapnel and gold plating layer. It is recommended to control the insertion and removal life within 10000 times; Regularly clean the interface dust with a dry soft bristled brush, and prohibit metal tools from touching the pins and springs to prevent scratching the coating.
Other taboos: It is prohibited to dismantle shrapnel, trim pins or replace the casing without authorization to avoid damaging electrical performance and structural stability; Prohibited for use in high temperature (>120 ℃), underwater and other scenarios beyond the design range; If the shrapnel fails, the gold plating layer falls off, or the contact is poor, it is necessary to immediately replace the new mother socket to avoid damaging the device motherboard.
