Product Description:

This TYPE C female connector features a 14PIN interface with side mount design, incorporating small pins at the front and fork pins at the rear, with a

pin length of 1.6mm. The product supports USB data transmission and power connection, making it suitable for various electronic devices, and is widely

used in consumer electronics, industrial equipment, automotive electronics, and more. Its compact design and easy installation offer stable connection

performance.

Key Features:

1. 14PIN Interface Design:

   Equipped with a 14PIN interface, supporting high-speed data transmission and power connection to meet device connection needs.

2. Side Mount Design:

   The side mount design is suitable for different sizes and spaces of circuit boards, simplifying installation and saving space.

3. Small Pins at Front, Fork Pins at Rear:

   The combination of small pins at the front and fork pins at the rear enhances the stability and firmness of the connection, ensuring reliable connectivity

for long-term use.

4. 1.6mm Pin Length:

   With a pin length of 1.6mm, the connector ensures good contact performance and stable insertion/extraction, providing more efficient data transmission.

Compliance Statement:

This product strictly adheres to international and industry certification standards, ensuring its compliance with safety and environmental regulations:

1. ISO 9001 Quality Management System Certification:

   Ensures the product meets international quality management standards during design and production.

2. REACH Certification:

   Complies with EU chemicals registration, evaluation, authorization, and restriction regulations, ensuring materials are safe and environmentally friendly.

3. RoHS Certification:

   Complies with the EU Restriction of Hazardous Substances (RoHS) directive, ensuring the product is free from harmful substances and promotes user health.

Contact Information:

- Hotline: 13310802726

- Email: mc13310802726@163.com

- Address: Dalingshan Town, Dongguan City, Guangdong Province

If you have any questions or need further information, feel free to contact us, and we will provide professional support.

TYPE C Female Connector 14PIN Side-Mount, Front Small Pins, Rear Forked Pins, Pin Length 1.6 USB Interface Usage Notes:

1. Installation and Operation:

   - During installation, ensure the front small pins and rear forked pins are properly soldered to the PCB pads to ensure secure connections and avoid poor

contact or signal interference.

   - When side-mounting, align the connector properly to avoid damaging the connector or device due to incorrect insertion.

2. Electrical Performance:

   - This connector uses high-quality metal materials to ensure excellent electrical transmission performance and stable data transfer.

   - The front small pin and rear forked pin design improves connector stability, making it ideal for high-frequency data transmission applications requiring

firm electrical contact.

3. Soldering Precautions:

   - During soldering, ensure the temperature and time are appropriately controlled to avoid excessive heat damage to the connector, affecting long-term

stability.

   - Ensure the solder joints are clean and avoid excessive solder during the soldering process to prevent short circuits or solder bridges.

4. Compatibility and Adaptability:

   - This connector is widely compatible with various devices supporting USB interfaces, especially suitable for applications requiring stable transmission and

high-reliability connections.

   - Designed for high current and high-frequency signal transmission, ensuring stability and reliability during extended use.

5. Application Scenarios:

   - Suitable for consumer electronics, industrial equipment, computer peripherals, and other fields requiring high data transfer rates.

   - Due to its stable electrical performance, it is widely used in long-term reliable connection scenarios such as audio and video transmission and mobile

devices.

6. Storage and Transportation:

   - Store in a dry, mild environment to prevent moisture or high temperatures from affecting its performance.

   - During transportation, avoid heavy impacts or compression to prevent damage to the connector pins or contact points.
