Product Description:

This TYPE C female connector features a 16PIN interface, side mount design, complies with three modes, and uses no-spring design with high

conductivity copper material to ensure good electrical performance and transmission efficiency. The product supports USB data transmission and

power connection, making it suitable for various electronic devices, and is widely used in consumer electronics, industrial equipment, automotive

electronics, and more.

Key Features:

1. 16PIN Interface Design:

   Equipped with a 16PIN interface, supporting high-speed data transmission and power connection to meet device connection needs.

2. Side Mount Design:

   The side mount design is suitable for different sizes and spaces of circuit boards, making installation simple and efficient.

3. Three Modes Support:

   Supports USB three modes, including USB 2.0, USB 3.0, and USB 3.1, offering faster transmission speeds for devices.

4. No Spring Design:

   The no-spring design reduces unnecessary contact force, ensuring a more stable connection and extending the product's lifespan.

5. High Conductivity Copper Material:

   Uses high conductivity copper material to improve transmission efficiency and ensure the stability of electrical performance.

Compliance Statement:

This product strictly adheres to international and industry certification standards, ensuring its compliance with safety and environmental regulations:

1. ISO 9001 Quality Management System Certification:

   Ensures the product meets international quality management standards during design and production.

2. REACH Certification:

   Complies with EU chemicals registration, evaluation, authorization, and restriction regulations, ensuring materials are safe and environmentally friendly.

3. RoHS Certification:

   Complies with the EU Restriction of Hazardous Substances (RoHS) directive, ensuring the product is free from harmful substances and promotes user

health.

Contact Information:

- Hotline: 13310802726

- Email: mc13310802726@163.com

- Address: Dalingshan Town, Dongguan City, Guangdong Province

If you have any questions or need further information, feel free to contact us, and we will provide professional support.

TYPE C Female Connector 16PIN Side-Mount CH=7.2 Three Modes, No Spring, High-Conductivity Copper USB Interface Usage Notes:

1. Installation and Operation:

   - During installation, ensure the connector is properly aligned with the PCB pads to avoid poor contact due to improper soldering. Especially with

side-mount installation, make sure the pads are positioned correctly to ensure a secure connection.

   - When in use, ensure the correct orientation for mating the connector to avoid damage or poor contact due to incorrect insertion.

2. Electrical Performance:

   - This connector is made from high-conductivity copper material, ensuring stable electrical connections and good signal transmission and electrical

performance.

   - Supports USB 3.0 standard with three modes (data transfer, power, ground), meeting high data transfer rate requirements.

3. Soldering Precautions:

   - During soldering, ensure the temperature and time are appropriately controlled to avoid damage to the connector.

   - Avoid excessive solder during the process to prevent short circuits or solder bridges. Ensure the solder joints are secure with good contact.

4. Applications and Compatibility:

   - This connector is suitable for various USB 3.0 devices, particularly applications requiring high transfer rates and electrical stability.

   - The springless design makes it ideal for more compact and stable devices, ensuring reliability over extended use.

5. Storage and Transportation:

   - Store in a dry, mild environment to avoid moisture or high temperatures that may affect connector performance.

   - During transportation, avoid heavy impacts or compression to prevent damage to the connector pins or contact points.
