Industry certification:

Protocol authentication: Certified by USB-IF (USB3.1 Gen2/PD3.0), VESA (DisplayPort 1.4), HDMI Association (HDCP 2.3).

Environmental certification: Compliant with RoHS 2011/65/EU (lead-free, halogen-free), ELV 2000/53/EC standards, LCP material recycling rate>90%.

Safety certification: UL 94 V-0 flame retardant rating, CE/FCC electromagnetic compatibility certification, IPX7 waterproof tested by a third-party laboratory.

Industry standards:

Industrial applications comply with ISO 13849-1 (PLd) mechanical safety standards, while automotive electronics meet AEC-Q200 Rev E and ISO 16750-2 requirements.

Quality control:

Each batch is sampled for salt spray testing (48 hours), thermal cycling testing (-40 ℃ to 105 ℃, 1000 times), and dynamic contact impedance testing (Δ R<10% after 100000 insertions and removals).

For more information, please contact us:

- Hotline: +86 13310802726

- Email: mc13310802726@163.com

Installation requirements:

Welding temperature: Reflow peak ≤ 255 ℃, maintain above 217 ℃ for 60-90 seconds. It is recommended to use nitrogen shielded welding (O ₂ content<100ppm) to avoid oxidation of LCP shell.

Positioning accuracy: The PCB pad tolerance should be controlled within ± 0.05mm for a height of 1.6mm. It is recommended to design positioning columns (with a diameter of 1.0mm) to assist in installation. After welding, use 3D AOI to check the pin offset to be less than 0.03mm.

Usage restrictions:

Non waterproof models are prohibited from being exposed to humid environments. Waterproof models require regular inspection of the sealing ring (fluororubber, replacement cycle 1-2 years).

When applying high current, the thickness of the PCB copper foil should be ≥ 50 μ m, and a 100nF ceramic capacitor (X7R) should be connected in parallel with the VBUS pin to suppress ripple and avoid overheating.

Compatibility Description:

The the third mock examination protocol requires device side chip support (such as TI TUSB8041). It is recommended to use USB-IF certified EMarker cable (such as USB4 Gen3).

Maintenance suggestion:

Clean interface dust with compressed air every quarter in industrial environments, wipe medical equipment with 75% ethanol, and prohibit chlorine containing disinfectants.

When idle for a long time, use LCP dust cover to protect the interface, store at a temperature of -20 ℃ to 60 ℃, humidity ≤ 60% RH, and prevent copper terminal oxidation.
