Certification standards:

USB-IF certification (USB2.0), IPX7 waterproof certification (IEC 60529), RoHS 2.0 environmental certification.

CE/FCC electromagnetic compatibility certification, ESD protection ± 8kV (contact discharge).

Quality control:

Sampling for each batch includes waterproof testing (30 minutes at a depth of 1 meter), contact impedance testing (less than 50m Ω after 5000 insertions and removals), and seal ring aging testing (200 ℃ × 1000h).

For more information, please contact us:

- Hotline: +86 13310802726

- Email: mc13310802726@163.com

Installation requirements:

Welding temperature ≤ 255 ℃, positioning column and PCB through-hole tolerance ± 0.05mm, it is recommended to use fixtures to ensure verticality.

Usage restrictions:

Long term immersion in water containing salt or chemical solvents is prohibited, and it is recommended to replace the waterproof ring once a year.

Maintenance suggestion:

Regularly clean the interface with anhydrous ethanol to avoid foreign objects blocking the waterproof sealing ring, and keep the interface dry during storage.
