This TYPE C female seat 6PIN vertical plug L=6.8 2.0 new straight edge non elastic regular foot length 0.8, strictly following international and domestic multi-dimensional authoritative standards, ensuring product safety, environmental protection, and adaptability to mainstream global markets. The specific compliance content is as follows:
Interface and transmission standard compliance: Fully compliant with the USB 2.0 specification published by the USB Implementers Forum (USB-IF), through USB 2.0 compatibility testing, ensuring compatibility with various USB 2.0 TYPE C male heads and devices - transmission speed, signal timing, power supply stability all meet the requirements of the USB 2.0 standard, avoiding charging interruption, data transmission lag and other problems caused by protocol incompatibility, and meeting the basic functional requirements of consumer electronic devices.
Environmental compliance: Fully comply with the EU RoHS 2.0 (2011/65/EU) directive and China's GB/T 26572-2011 "Limit Requirements for Restricted Substances in Electronic and Electrical Products", strictly limit the content of 10 harmful substances such as lead (Pb), mercury (Hg), cadmium (Cd), hexavalent chromium (Cr6+), polybrominated biphenyls (PBBs), and polybrominated diphenyl ethers (PBDEs). All raw materials (plastic casing, pin metal) have undergone environmental testing and can provide RoHS compliance reports issued by third-party testing agencies such as SGS and TUV. They are suitable for markets with strict environmental requirements such as the European Union, North America, and Japan, and have no market access barriers.
Electrical safety compliance: Complies with IEC 62368-1 "Audio, Video, Information Technology, and Communication Technology Equipment Part 1: Safety Requirements", with electrical performance indicators meeting standards - insulation resistance ≥ 100M Ω (500V DC), withstand voltage ≥ 500V AC (no breakdown or arcing for 1 minute), effectively preventing short circuit and leakage risks; Simultaneously meeting the US FCC Part 15 Class B electromagnetic compatibility (EMC) standard, the electromagnetic radiation during signal transmission is ≤ 54dB μ V/m (30MHz~1GHz frequency band), avoiding interference with surrounding electronic components (such as Bluetooth modules and sensors in smart wearable devices), and ensuring stable operation of the device.
Production and Quality Compliance: The production process strictly follows the ISO 9001 quality management system and establishes a full process control of "raw materials production finished products". Raw materials need to provide supplier qualification certificates, and sampling inspections are conducted every hour during production (including appearance, foot length, and conductivity). Finished products must pass 100% electrical performance tests (contact impedance, insulation) and visual inspections (no scratches, deformation, or bent pins), with a non conformance rate controlled below 0.1%. We can provide batch quality inspection reports according to customer needs to ensure consistent performance and stable quality of each batch of products, meeting the quality requirements of mass production.


For more information, please contact us:

- Hotline: +86 13310802726

- Email: mc13310802726@163.com

To ensure the performance, installation stability, and service life of the Type C female seat 6PIN vertical plug L=6.8 2.0 new straight edge non elastic regular foot length 0.8, the following precautions must be strictly followed:
Storage and transportation precautions: The product should be stored in a dry and clean environment with a temperature of -5 ℃~35 ℃ and a relative humidity of 25%~55%. Avoid storing in high temperature and high humidity (such as near humidifiers or sinks), direct sunlight, or places with dust or corrosive gases (such as alcohol and rosin) to prevent aging of the plastic shell and oxidation and rusting of the pin coating; During transportation, anti-static packaging (anti-static shielding bag+anti-static turnover box) should be used, and the packaging should be labeled with "anti-static" and "handle with care" signs to avoid violent handling that may cause the mother seat shell to break or the pins to bend; After opening the packaging, unused products must be resealed within 24 hours. Prolonged exposure to air is prohibited to prevent the pins from becoming damp and oxidized.
Precautions for installation operation: Before installation, it is necessary to confirm that the depth of the PCB board solder pads matches the foot length (0.8mm foot length requires solder pad depth ≥ 0.6mm), and the size of the solder pads should meet the requirements of the product specification (error ≤± 0.05mm), to avoid shallow solder pads causing exposed pins and deep solder pads causing the mother seat to tilt; When using SMT vertical insertion and placement, strictly control the reflow soldering temperature curve: preheating section 90 ℃~120 ℃ (lasting 60~90 seconds), peak section 240 ℃~260 ℃ (lasting ≤ 8 seconds), cooling section ≤ 50 ℃. Excessive temperature or prolonged high temperature time will cause the plastic shell to soften and the pins to separate from the shell; After installation, AOI (automatic optical inspection) or high-power magnifying glass inspection is required to confirm that the mother base is not tilted (tilt angle ≤ 1 °), the pins are not offset, and there is no virtual soldering/connection soldering. If any abnormalities are found, professional tools should be used for repair. It is forbidden to enter the next process with defects.
Precautions for use and maintenance: When using, the input current should not exceed 3A rated value. It is forbidden to connect power adapters that exceed 3A (such as 65W fast charging heads) to avoid long-term overload that may cause pin overheating, burning, or plastic shell melting; When plugging and unplugging the TYPE C male head, it should be operated vertically and steadily, and tilting, rotating, or pulling with force is prohibited. Although the non elastic structure simplifies the design, excessive wear can lead to poor contact (it is recommended to control the plugging and unplugging life within 5000 times); For devices that are frequently plugged in and out (such as mini chargers), it is necessary to regularly check whether there is dust or foreign matter inside the mother socket. If there is, a dry soft bristled brush can be used to gently clean it. It is forbidden to use metal tools (such as tweezers, needles) to enter the interior to prevent scratching the pins; When repairing the equipment, it is necessary to first disconnect the power supply, and then use professional tools to disassemble the PCB board. It is forbidden to directly bend the mother seat to avoid pin breakage or separation between the mother seat and the PCB board.
