This TYPE C female seat 6PIN upright sticker L=5.15 2.0 new rolled edge non elastic strictly follows international and domestic authoritative standards to ensure product safety, environmental protection, and adaptability to the global market. The specific compliance content is as follows:
Interface and transmission standard compliance: Fully compliant with the USB 2.0 specification published by the USB Implementers Forum (USB-IF), through USB 2.0 compatibility testing, ensuring compatibility with various USB 2.0 TYPE C male heads and devices, transmission speed, and signal stability meet the requirements of the USB 2.0 standard (480Mbps), avoiding charging abnormalities, data transmission failures, and other issues caused by protocol incompatibility, and meeting the basic transmission needs of consumer electronic devices.
Environmental compliance: Fully compliant with the EU RoHS 2.0 (2011/65/EU) directive and China's GB/T 26572-2011 "Limit Requirements for Restricted Substances in Electronic and Electrical Products", strictly limiting the content of 10 harmful substances such as lead (Pb), mercury (Hg), cadmium (Cd), hexavalent chromium (Cr6+), polybrominated biphenyls (PBBs), polybrominated diphenyl ethers (PBDEs), etc. All raw materials undergo environmental testing and can provide RoHS compliance reports issued by third-party testing agencies such as SGS and TUV, suitable for markets with high environmental requirements worldwide (such as the EU, North America, Japan).
Electrical safety compliance: Complies with IEC 62368-1 "Audio, Video, Information Technology, and Communication Technology Equipment Part 1: Safety Requirements", insulation resistance ≥ 100M Ω (500V DC), withstand voltage ≥ 500V AC (no breakdown or arcing for 1 minute), effectively preventing short circuit and leakage risks; Simultaneously meeting the US FCC Part 15 Class B electromagnetic compatibility (EMC) standards, reducing electromagnetic radiation during signal transmission, avoiding interference with surrounding electronic components (such as sensors and Bluetooth modules in smart wearable devices), and ensuring stable device operation.
Production and Quality Compliance: The production process strictly follows the ISO 9001 quality management system, from raw material procurement, production processing to finished product delivery, establishing a full process quality control mechanism - raw materials need to provide a certificate of conformity, sampling inspection is conducted every 2 hours during production (including appearance, conductivity, and dimensional accuracy), and finished products need to pass 100% electrical performance testing and appearance inspection, with a failure rate controlled below 0.1%. Batch quality inspection reports can be provided according to customer needs to ensure consistent performance and stable quality of each batch of products.


For more information, please contact us:

- Hotline: +86 13310802726

- Email: mc13310802726@163.com

Storage and transportation precautions: The product should be stored in a dry and clean environment with a temperature of -5 ℃~35 ℃ and a relative humidity of 25%~55%. Avoid storing in high temperature and high humidity (such as near water sources, air conditioning vents), direct sunlight, or places with dust or corrosive gases (such as alcohol and formaldehyde) to prevent aging of the plastic shell and oxidation and rusting of the pin coating; During transportation, anti-static packaging (such as anti-static shielding bags, anti-static turnover boxes) should be used, and the packaging should be labeled with "Handle with care" and "Anti static" signs to avoid violent handling that may cause deformation of the mother seat shell and bending of the pins; After opening the packaging, unused products must be resealed and stored within 24 hours. Prolonged exposure to air is prohibited to prevent the pins from getting damp and oxidized.
Precautions for installation operation: Before installation, it is necessary to confirm that the size of the PCB board solder pads matches the pins of the mother socket (please refer to the solder pad design diagram in the product specification book, and the solder pad error should be ≤± 0.05mm), to avoid solder joints caused by large solder pads and virtual soldering caused by small solder pads; When using the vertical bonding process for mounting, it is necessary to strictly control the reflow soldering temperature curve - preheating temperature of 90 ℃~120 ℃ (lasting 60~90 seconds), peak temperature of 240 ℃~260 ℃ (lasting ≤ 8 seconds), cooling temperature ≤ 50 ℃. Excessive temperature or prolonged high temperature duration can cause deformation of the plastic shell and separation of pins from the shell; After installation, the installation quality needs to be checked through AOI (automatic optical inspection) or high-power magnifying glass to confirm that the mother seat is not tilted (tilt angle ≤ 1 °), the pins are not offset, and there is no virtual soldering/connection soldering. If any abnormalities are found, they should be repaired in a timely manner. It is forbidden to enter the next process with defects.
Precautions for use and maintenance: During use, it is necessary to ensure that the input current does not exceed the rated value of 3A, avoid long-term overload (such as connecting a power adapter that exceeds 3A), prevent pin overheating and burning, and prevent plastic shell melting; When plugging and unplugging the Type-C male connector, it should be done vertically and smoothly, without tilting, pulling or rotating, to reduce the wear of the female socket pins - although the non elastic structure simplifies the design, excessive wear can lead to poor contact and shorten the service life (it is recommended to control the plugging and unplugging life within 5000 times); For devices such as smart wearables and TWS earphones that are frequently plugged in and out, it is necessary to regularly check whether there is dust or foreign matter inside the mother socket. If there is, a dry soft bristled brush should be used to gently clean it. It is forbidden to use metal tools (such as tweezers) to enter the mother socket to avoid scratching the pins; When repairing equipment, it is necessary to first disconnect the power supply and then use professional tools to disassemble the PCB board. It is forbidden to directly break the mother seat to prevent it from separating from the PCB board.
