Product Description:

This product is a Type-C USB female connector with a 6Pin interface design, 1.6mm sunk thickness, and a two-pin board structure. Compliant with the USB

2.0 standard, it supports high-speed data transmission and is suitable for connecting various electronic devices. The new model features a flange design,

enhancing the stability and durability of the connector. It is widely used in consumer electronics, industrial equipment, and other fields.

Key Features:

1. USB 2.0 Interface Standard:

   This product complies with USB 2.0 standards and supports 480Mbps high-speed data transmission, meeting the connection needs of most devices.

2. 6Pin Interface Design:

   The 6Pin interface design ensures stable data transmission and is compatible with various USB 2.0 devices.

3. 1.6mm Sunk Thickness:

   The sunk design provides a more stable connection, ideal for PCB board installation, and enhances the product’s pressure resistance.

4. Two Pin Board Structure:

   The two-pin board structure improves the stability and durability of the connector, ensuring reliable connections.

5. Flange Design:

   The flange design effectively increases the mechanical strength of the product and improves the connector's resistance to interference.

Compliance Statement:

This product strictly adheres to international and industry certification standards, ensuring its compliance with safety and environmental regulations:

1. ISO 9001 Quality Management System Certification:

   Ensures the product meets international quality management standards during design and production.

2. REACH Certification:

   Complies with the EU chemicals registration, evaluation, authorization, and restriction regulations, ensuring the materials are safe and environmentally

friendly.

3. RoHS Certification:

   Complies with the EU Restriction of Hazardous Substances (RoHS) directive, ensuring the product is free from harmful substances and promotes user

health.

Contact Information:

- Hotline: 13310802726

- Email: mc13310802726@163.com

- Address: Dalingshan Town, Dongguan City, Guangdong Province

If you have any questions or need further information, feel free to contact us, and we will provide professional support.

Type-C Female Connector 6Pin SMD 1.6mm Two-Pin Board-Mount L=5.1 With Flange USB 2.0 New Version Usage Notes:

1. Installation and Soldering:

   - Ensure the soldering area is clean, free from oil or dust, to maintain soldering quality.

   - The soldering temperature should be strictly controlled within the recommended range, as excessive heat may damage the connector or PCB.

   - Ensure the connector is correctly aligned with the PCB during installation and securely soldered to prevent poor contact.

2. Electrical Performance:

   - This product conforms to USB 2.0 standards and supports data transmission, ensuring stable data flow and electrical connections.

   - The SMD design offers excellent electrical performance, ideal for compact devices or high-density PCB applications.

   - The flange design enhances the structural stability of the connector, ensuring a firm connection between the plug and socket.

3. Insertion and Extraction:

   - Handle insertion and extraction gently to avoid excessive force, ensuring proper alignment of the plug and socket to avoid damage.

   - During insertion, align the plug with the socket to ensure stable electrical connection.

4. Material Properties:

   - The housing is made from high-strength materials that offer excellent corrosion resistance and oxidation resistance for long-term stable use.

   - The pins are made from high-conductivity materials to ensure electrical stability during high-speed data transmission.

5. Operating Environment:

   - This product is widely used in consumer electronics, communication devices, computer interfaces, and other applications.

   - Avoid use in high-temperature, high-humidity, or corrosive environments to ensure the stable performance of the connector.

6. Storage Conditions:

   - Store unused products in a dry, ventilated environment, away from direct sunlight.

   - Avoid storing in extreme temperatures to prevent material aging or performance degradation.

For more product information or technical support, please contact us:

- Hotline: 13310802726

- Email: mc13310802726@163.com
