Product name: CH=5.06 three-mode LCP USB4.0 interface with elastic and high conductivity copper is attached to the 24Pin side of Type-C mother seat.

Product description:

This product is a high-performance Type-C USB socket, with 24Pin interface and side-mounted design, which conforms to USB4.0 standard and supports

 three-mode function. Using high copper conductivity material and LCP (liquid crystal polymer) shell, it has excellent electrical conductivity and high

temperature resistance. Built-in elastic design enhances the stability of connection, and is widely used in electronic devices that need high-speed data

transmission and high-power charging.

Main features:

1. USB4.0 interface:

It conforms to USB4.0 standard, supports high-speed data transmission and high-power charging, and improves the performance and experience of

equipment.

2. 24Pin interface design:

24Pin design supports more functions, such as high-speed data transmission, video output and power transmission, and meets various application

requirements.

3. Three-die design:

Support three-mode function, adapt to the compatibility of different devices, and improve the convenience of multi-function use.

4. High conductivity copper material:

The use of high-conductivity copper materials ensures lower resistance and higher conductivity, and ensures the stable transmission of signals and power.

5. LCP shell:

Using LCP (liquid crystal polymer) shell, it has excellent high temperature resistance, corrosion resistance and mechanical strength, and is suitable for

applications in harsh environments.

6. Projectile design:

Built-in elastic design enhances the firmness and stability of connection, prevents poor contact and improves service life.

Statement of compliance:

This product strictly abides by international and industry certification standards to ensure its compliance in safety and environmental protection:

1. ISO 9001 quality management system certification:

Ensure that products meet international quality management standards in the design and production process.

2. REACH certification:

Comply with EU regulations on registration, evaluation, authorization and restriction of chemicals, and ensure that the materials are harmless and

environmentally friendly.

3. RoHS certification:

Comply with the EU directive on the restriction of harmful substances in electronic and electrical equipment, ensure that the products do not contain

harmful substances and protect the health of users.

Contact information:

-Hotline: 13310802726

-E-mail: mc13310802726@163.com

-Company Address: Dalingshan Town, Dongguan City, Guangdong Province

If you have any questions or need further understanding, please feel free to contact us and we will provide you with professional support.

On the 24Pin side of Type-C female socket, attach CH=5.06. Points for attention in using LCP USB4.0 interface with three-mode elastic and high

conductivity copper:

1. Installation and welding:

-Please ensure that the welding surface is clean during installation, so as to avoid oil pollution or dust affecting the welding quality.

-The welding temperature should be controlled within the specified range. Excessive temperature may affect the stability of the internal structure

of the interface.

-The welding feet of the socket should be firmly welded to ensure the stability and reliability of the connection.

2. Electrical performance:

-This product supports USB4.0 standard and can provide high data transmission rate and power transmission. Please ensure the compatibility between

 the device and the interface.

-The interface is designed to support the maximum current transmission, so that it can be used within the rated range to ensure the normal operation

and long-term use of the interface.

3. Plug-in operation:

-Please ensure that the operation is gentle when plugging and unplugging, so as to avoid excessive contact between the plug and the socket, so as to

avoid damaging the contact points.

-When plugging and unplugging, it should follow the forward plugging and unplugging, so as to avoid the asymmetric insertion of the plug into the

interface, which may cause the interface damage or poor contact.

-Plugging times should be controlled within the design requirements to avoid excessive wear.

4. Three models:

-This interface supports USB 3.1, USB 2.0 and power transmission (PD) functions, and supports high-bandwidth USB4.0 data transmission.

-Please ensure that the equipment and cables used comply with the USB4.0 standard for the best performance.

5. Material characteristics:

-This interface is made of high copper conductivity and LCP material, which has good electrical conductivity and thermal stability and can work stably

at high temperature.

-The use of LCP materials helps to improve the heat resistance and corrosion resistance, thus prolonging the service life of products.

6. Cleaning and maintenance:

-If the interface surface is contaminated with moisture or dust, please wipe it with a clean and soft cloth in time to avoid using chemical cleaners.

-Check the spring contact point of the interface regularly to ensure that it is not damaged or aged, and maintain the stability and good contact of the

interface.

7. Application environment:

-This product is suitable for high-bandwidth applications, such as high-performance computing and high-definition video transmission, but it is not

recommended to be exposed to high temperature, high humidity or corrosive environment for a long time.

-Avoid strong mechanical impact or scratches on the interface, so as not to affect the interface performance.

8. Storage conditions:

-Unused products should be stored in a dry, cool and ventilated environment to avoid direct sunlight.

-Please avoid storing the product in an environment with too high or too low temperature, so as not to affect the product performance.
