Industry certification:

USB-IF (USB3.1 Gen2/PD3.1), VESA (DisplayPort 1.4), HDMI Association (HDCP 2.3) certification.

RoHS 2011/65/EU, REACH SVHC 235 items, LCP recyclability rate>95%.

UL 94 V-0 flame retardant, CE/FCC electromagnetic compatibility, IPX7 waterproof passed CNAS testing.

Production control:

Sampling per batch: high current temperature rise test (5A/2 hours, terminal temperature ≤ 75 ℃), dynamic contact impedance test (Δ R<15% after 100000 insertions and removals).

For more information, please contact us:

- Hotline: +86 13310802726

- Email: mc13310802726@163.com

Installation requirements:

Reflow peak temperature ≤ 255 ℃, maintain above 217 ℃ for 60-90 seconds. It is recommended to use a 0.01mm precision surface mount machine and 3D AOI to detect solder joint offset<0.03mm.

Usage restrictions:

Non waterproof models are prohibited from humid environments, and waterproof sealing rings are recommended to be replaced annually; When using 5A, the PCB copper foil should be ≥ 50 μ m, and the VBUS line width should be ≥ 1.5mm.

Compatibility Description:

The third mock examination requires device side chip support (such as Ruiyu RTS5490). It is recommended to use USB-IF certified 40Gbps EMarker cable.

Maintenance suggestion:

Compressed air cleaning for industrial environments every quarter, wiping medical equipment with 75% ethanol, and prohibiting chlorine containing disinfectants; Long term idle needs to be sealed with a dust cover and stored at a humidity of ≤ 40% RH.
