Industry certification:

USB-IF certification: Through strict certification by the USB-IF Association, it fully complies with the USB3.1 standard, ensuring compatibility with various USB devices and stable and reliable data transmission.

Waterproof certification: Tested according to the international standard IEC 60529, obtained IPX6 waterproof rating certification, proving that the product's waterproof performance has reached the industry recognized level.

Environmental certification: The product complies with the requirements of the EU RoHS 2011/65/EU directive, does not contain harmful substances such as lead, mercury, cadmium, etc., and meets the ELV 2000/53/EC environmental standards. It is green and environmentally friendly, in line with the concept of sustainable development.

Industry standards:

For industrial applications, meeting the ISO 13849-1 mechanical safety standard ensures the safety and reliability of connectors in complex operating environments of industrial machinery.

In terms of automotive electronic applications, it complies with relevant standards in the automotive industry and has undergone multiple rigorous tests such as vibration and impact, making it suitable for harsh internal use conditions in automobiles.

Production control:

The entire production process is managed using an advanced ERP system, with traceability at every stage from raw material procurement, production and processing to finished product inspection, ensuring controllable product quality.

Each batch of products undergoes 100% electrical performance testing, including contact impedance testing, insulation resistance testing, withstand voltage testing, and simulated IPX6 waterproof environment water spray testing to ensure product quality meets high standards.

For more information, please contact us:

- Hotline: +86 13310802726

- Email: mc13310802726@163.com

Installation requirements:

During welding, it is essential to strictly control the temperature. The peak value of the reflow soldering temperature curve should be controlled within 255 ° C, and the duration should not exceed 60 seconds to avoid damage to the terminals and LCP insulation caused by high temperatures.

During the SMT installation process of the four pin plug-in board, a high-precision surface mount machine is required to ensure precise alignment between the pins and PCB pads, with a deviation controlled within ± 0.05mm, in order to achieve good electrical connection and stable mechanical performance.

Usage restrictions:

Although the product has IPX6 waterproof performance, it should be avoided from being immersed in water for a long time to prevent the risk of water leakage caused by slight gaps in the encapsulated part.

In practical use, the current load should be reasonably selected based on factors such as the thickness of the PCB copper foil. If the thickness of the PCB copper foil is less than 35 μ m, it is recommended that the current not exceed 2A to prevent overheating of the circuit.

Compatibility Description:

When connected to a USB 2.0 device, the data transfer rate automatically drops to 480Mbps; Connected to devices that support USB 3.1, it can achieve high-speed transmission of 5Gbps.

Using cables without USB-IF certification may result in unstable data transmission, abnormal charging, and other issues. It is recommended to use certified cables to maximize product performance.

Maintenance suggestion:

Regularly use compressed air or anti-static brushes to clean the dust and debris inside the interface, to prevent the accumulation of foreign objects from affecting contact performance or causing short circuits.

If the device is not used for a long time, it is recommended to use a dust plug to protect the interface and avoid oxidation and deformation, thereby extending the product's service life.
