Product Description:

This waterproof Type-C USB female connector features a 16Pin interface, a four-leg SMT mount design, and a length of 7.5mm, made with high-quality

zinc alloy material. The product has an IPX7 waterproof rating, ensuring stable performance in humid environments. It is suitable for data transmission

and power connection in various electronic devices, widely used in consumer electronics, industrial equipment, automotive electronics, and more.

Key Features:

1. Waterproof Design:

   The product has an IPX7 waterproof rating, preventing moisture from entering and ensuring reliable performance in humid environments.

2. 16Pin Interface:

   The 16Pin design ensures stable USB data transmission and power connection, meeting the needs of various devices.

3. Four-Leg SMT Mount Design:

   The Surface-Mount Technology (SMT) design simplifies the installation process, making it suitable for automated production and efficient assembly.

4. Zinc Alloy Material:

   Made with zinc alloy material, this connector offers excellent corrosion resistance and durability, enhancing mechanical strength and improving

connection stability.

5. Compact Size:

   The compact design with a length of 7.5mm is suitable for devices with limited space, making installation convenient and widely applicable.

Compliance Statement:

This product strictly adheres to international and industry certification standards, ensuring its compliance with safety and environmental regulations:

1. ISO 9001 Quality Management System Certification:

   Ensures the product meets international quality management standards during design and production.

2. REACH Certification:

   Complies with the EU chemicals registration, evaluation, authorization, and restriction regulations, ensuring materials are safe and environmentally

friendly.

3. RoHS Certification:

   Complies with the EU Restriction of Hazardous Substances (RoHS) directive, ensuring the product is free from harmful substances and promotes user

health.

Contact Information:

- Hotline: 13310802726

- Email: mc13310802726@163.com

- Address: Dalingshan Town, Dongguan City, Guangdong Province

If you have any questions or need further information, feel free to contact us, and we will provide professional support.

Waterproof Type-C Female Connector 16Pin 4-Leg SMT L=7.5 Zinc Alloy USB Interface Usage Notes:

1. Installation and Soldering:

   - Ensure that the PCB pads are aligned with the connector pins before installation to avoid poor contact due to misalignment.

   - Use appropriate soldering temperature and time to prevent damage to the connector and PCB from excessive heat.

   - After soldering, check the firmness of the solder joints to ensure each pin is securely attached.

2. Waterproof Performance:

   - This product features waterproof capabilities, suitable for environments with high humidity or exposure to water.

   - Ensure that the waterproof seal is intact during installation to prevent water ingress that could cause electrical failure.

   - Conduct waterproof performance testing before use to ensure compliance with IP standards.

3. Electrical Performance:

   - Supports high-speed data transmission and complies with USB standards, suitable for a wide range of electronic devices.

   - Made with high-conductivity materials to ensure low contact resistance, providing stable electrical performance and long-term reliability.

4. Insertion and Extraction:

   - Avoid excessive force when inserting or extracting the connector to prevent damage to the connector or pins.

   - Ensure the correct orientation when inserting the connector to avoid poor contact or mechanical damage.

5. Materials and Design:

   - The connector housing is made of zinc alloy, providing good strength and corrosion resistance.

   - Optimized pin and waterproof structure design ensures stability and durability in harsh environments.

6. Application Scenarios:

   - Suitable for consumer electronics, automotive electronics, industrial devices, and other applications requiring waterproof protection.

   - Regular inspection is recommended when used in environments with high humidity, high temperature, or corrosive gases.

7. Storage and Transportation:

   - Store in a dry, cool, and shaded place, avoiding direct sunlight and damp environments.

   - During transportation, avoid strong impacts to prevent damage to the connector and pins.
