Product compliance description

Product name: Type-C mother seat 16Pin sinker 0.8 four-pin plug-in board SMT L=6.5 three-mode brass 5A current USB interface

Product description:

This product is a high-performance Type-C USB socket, with 16Pin interface, sinking plate design of 0.8, and equipped with four-pin board SMT, which

conforms to USB interface standard and supports 5A current. Compact and sturdy design, suitable for all kinds of consumer electronics.

Industrial equipment and other application scenarios. Brass material is used to ensure excellent conductivity and durability, support three-mode function

and meet the connection requirements of various devices.

Main features:

1. 5A current support:

It has 5A current carrying capacity, meets the requirements of high-power transmission, and is suitable for equipment requiring high-speed data and charging.

2. 16Pin interface design:

16Pin design conforms to USB standard, supports high-speed data transmission and power transmission, and is suitable for the connection of various

electronic devices.

3. 0.8mm design of sinker:

Sinking plate design provides higher connection stability, enhanced durability and anti-interference ability.

4. Four-pin board SMT:

SMT design ensures high-precision installation and firm connection, and enhances the overall mechanical strength.

5. Brass material:

Made of brass material, it has excellent conductivity and corrosion resistance, ensuring reliable performance in long-term use.

6. Three-mode function:

Support data transmission, video output and power transmission to enhance multi-functional compatibility.

Statement of compliance:

This product strictly abides by international and industry certification standards to ensure its compliance in safety and environmental protection:

1. ISO 9001 quality management system certification:

Ensure that products meet international quality management standards in the design and production process.

2. REACH certification:

Comply with EU regulations on registration, evaluation, authorization and restriction of chemicals, and ensure that the materials are harmless and

environmentally friendly.

3. RoHS certification:

Comply with the EU directive on the restriction of harmful substances in electronic and electrical equipment, ensure that the products do not contain

harmful substances and protect the health of users.

Contact information:

-Hotline: 13310802726

-E-mail: mc13310802726@163.com

-Company Address: Dalingshan Town, Dongguan City, Guangdong Province

If you have any questions or need further understanding, please feel free to contact us and we will provide you with professional support.

Type-C Female Connector 16Pin SMD 0.8mm Thru-Hole Four Pin SMT L=6.5 Three Modes Brass 5A Current USB Interface Usage Notes:

1. Installation and Soldering:

   - Ensure that the soldering surface is clean before installation to prevent oil or dust from affecting the soldering quality.

   - The soldering temperature should be controlled within the recommended range to avoid damaging the internal structure of the connector.

   - The four-pin solder pads should be securely soldered to ensure stable connections and long-term reliability.

2. Electrical Performance:

   - This product is designed for a maximum current of 5A. Please ensure it is used within the rated current range for normal operation and to extend

its lifespan.

   - Avoid overloading or applying abnormal voltage to prevent damage to the connector and related circuits.

3. Insertion and Extraction:

   - Handle the insertion and extraction gently to avoid violent contact between the plug and the socket, which could damage the contact points.

   - Always insert the connector in the correct direction to avoid asymmetrical insertion that could lead to connector damage or poor contact.

   - The number of insertions and extractions should be controlled within the specified range to prevent excessive wear.

4. Three-Mode Features:

   - This connector supports USB 3.1, USB 2.0, and Power Delivery (PD) functionality. Ensure that your devices are compatible with the three-mode

interface.

   - During use, pay attention to device compatibility to ensure stable connections and efficient data transmission in all modes.

5. Material Properties:

   - The connector is made of brass, providing good electrical conductivity and corrosion resistance for stable electrical connections.

   - Avoid exposure to high temperatures or humid environments to maintain optimal connector performance.

6. Cleaning and Maintenance:

   - If the interface accumulates moisture or dust, promptly wipe it with a clean, soft cloth, and avoid using chemical cleaning agents.

   - Regularly inspect the connector's pins for any damage or aging, ensuring reliable contact.

7. Operating Environment:

   - This product is suitable for general electronic devices and industrial control applications, but prolonged exposure to high temperatures, high

humidity, or corrosive environments should be avoided.

   - Protect the connector from strong mechanical impacts or scratches to ensure proper insertion and functionality.

8. Storage Conditions:

   - Unused products should be stored in a dry, cool, and well-ventilated environment, away from direct sunlight.

   - Avoid storing the product in environments with extreme temperatures to prevent damage and performance degradation.
