Product Description:

This product is a high-performance Type-C USB female connector with a 16Pin interface design, 1.2mm board-mount installation, and supports 5A

current transmission. It features a 4-pin board structure for excellent stability, making it ideal for high-power data transmission. It is widely used in

consumer electronics, industrial equipment, automotive electronics, and other fields.

Key Features:

1. 5A Current Support:

   This product supports 5A current transmission, making it suitable for high-power devices and ensuring safe and efficient data transfer.

2. 16Pin Interface Design:

   The 16Pin interface design supports high-speed data transmission, meeting the connection needs of various USB devices.

3. 1.2mm Board-Mount Installation:

   The 1.2mm board-mount design ensures stable connections and enhances resistance to interference.

4. 4-Pin Board Structure:

   The 4-pin board structure improves the stability and durability of the interface, suitable for high-load environments.

5. Broad Compatibility:

   Suitable for a wide range of devices, particularly in consumer electronics, industrial equipment, and automotive electronics.

Compliance Statement:

This product strictly adheres to international and industry certification standards, ensuring its compliance with safety and environmental regulations:

1. ISO 9001 Quality Management System Certification:

   Ensures the product meets international quality management standards during design and production.

2. REACH Certification:

   Complies with the EU chemicals registration, evaluation, authorization, and restriction regulations, ensuring the materials are safe and environmentally

friendly.

3. RoHS Certification:

   Complies with the EU Restriction of Hazardous Substances (RoHS) directive, ensuring the product is free from harmful substances and promotes user

health.

Contact Information:

- Hotline: 13310802726

- Email: mc13310802726@163.com

- Address: Dalingshan Town, Dongguan City, Guangdong Province

If you have any questions or need further information, feel free to contact us, and we will provide professional support.

Type-C Female Connector 16Pin Recessed 1.2mm 4-Pin Board-Mount SMT L=6.5 5A Current USB Interface Usage Notes:

1. Installation and Soldering:

   - Before soldering, ensure the soldering area is clean and free of debris to avoid poor soldering.

   - Use standard-compliant soldering tools and control the temperature to prevent damage to the connector or PCB.

   - Make sure the connector is properly aligned with the PCB and that the four pins are securely soldered for reliable contact.

2. Electrical Performance:

   - This product supports USB standards and allows up to 5A current, making it suitable for high-speed data transfer and charging.

   - The recessed design enhances mechanical strength and durability, ideal for compact devices.

   - Made with high-conductivity materials to ensure stable electrical performance even under high current conditions.

3. Insertion and Extraction:

   - Insert and extract the plug gently to avoid excessive force and ensure a secure connection.

   - During insertion, ensure the plug is fully aligned with the socket to prevent poor contact or damage.

4. Material Properties:

   - The housing is made of durable materials with excellent corrosion and oxidation resistance for long-term use.

   - Pins are made from high-conductivity brass to ensure stable and efficient electrical connections.

5. Operating Environment:

   - Widely used in computers, mobile devices, consumer electronics, and other electronic equipment.

   - Avoid use in environments with high humidity, high corrosion, or extreme temperatures to maintain stable performance.

6. Storage Conditions:

   - Store the product in a dry, ventilated environment, avoiding direct sunlight and moisture.

   - Do not store the product in extreme temperatures to prevent material aging or performance degradation.
