Product Description:

This product is a high-performance Type-C USB female connector with a 16Pin interface design, 1.0mm board-mount installation, and supports 5A current

transmission. It features a 4-pin board structure that ensures stable connection performance, making it suitable for high-power data transmission. It is widely

used in consumer electronics, industrial equipment, automotive electronics, and other fields.

Key Features:

1. 5A Current Support:

   This product supports 5A current transmission, making it suitable for high-power devices and ensuring safe and efficient data transmission.

2. 16Pin Interface Design:

   The 16Pin interface design supports high-speed data transmission, meeting the connection needs of various USB devices.

3. 1.0mm Board-Mount Installation:

   The 1.0mm board-mount design ensures more stable connections and provides better resistance to interference.

4. 4-Pin Board Structure:

   The 4-pin board structure enhances the stability of the connection, making the interface more durable and suitable for high-load environments.

5. High Compatibility:

   Suitable for a wide range of devices, particularly in consumer electronics, industrial equipment, automotive electronics, and more.

Compliance Statement:

This product strictly adheres to international and industry certification standards, ensuring its compliance with safety and environmental regulations:

1. ISO 9001 Quality Management System Certification:

   Ensures the product meets international quality management standards during design and production.

2. REACH Certification:

   Complies with the EU chemicals registration, evaluation, authorization, and restriction regulations, ensuring the materials are safe and environmentally

friendly.

3. RoHS Certification:

   Complies with the EU Restriction of Hazardous Substances (RoHS) directive, ensuring the product is free from harmful substances and promotes user

health.

Contact Information:

- Hotline: 13310802726

- Email: mc13310802726@163.com

- Address: Dalingshan Town, Dongguan City, Guangdong Province

If you have any questions or need further information, feel free to contact us, and we will provide professional support.

Type-C Female Connector 16Pin SMD Board-Mount L=6.5 5A Current USB Interface Usage Notes:

1. Installation and Soldering:

   - Ensure the soldering area is clean and free from oil, dust, or debris before installation.

   - During soldering, maintain the temperature within the recommended range to avoid damaging the connector or PCB.

   - Ensure the connector is properly aligned with the PCB and securely soldered to prevent poor contact or short circuits.

2. Electrical Performance:

   - This product supports USB standards and allows for 5A current, suitable for high-speed data transfer and power supply.

   - The SMD design provides flexibility for high-density layouts and is ideal for compact devices.

   - The use of high-conductivity materials ensures excellent electrical performance even at high currents.

3. Insertion and Extraction:

   - Handle insertion and extraction gently, avoiding excessive force to ensure a stable connection between the plug and socket.

   - Ensure the plug is properly aligned with the socket during insertion to avoid poor contact.

4. Material Properties:

   - The housing is made from durable materials with excellent corrosion and oxidation resistance.

   - The internal pins are made from high-conductivity materials, ensuring stable electrical connections.

5. Operating Environment:

   - This product is widely used in computers, consumer electronics, communication devices, and other applications.

   - Avoid use in excessively humid or corrosive environments to ensure stable performance.

6. Storage Conditions:

   - Store the product in a dry, ventilated environment, away from direct sunlight when not in use.

   - Avoid storing the product in extreme temperatures to prevent material degradation or performance loss.
