Product Description:

This TYPE C female connector features a 14PIN interface design, clamp installation, five solder pads, and a built-in 5.1K resistor, supporting OTG

functionality, and complies with USB interface standards. It is suitable for data transmission and power connection, with OTG functionality enabling

data exchange between devices. This product is widely used in consumer electronics, industrial equipment, and other fields.

Key Features:

1. 14PIN Interface Design:

   Equipped with a 14PIN interface, supporting high-speed data transmission and power connection to meet device connection needs.

2. Clamp Design:

   The clamp design ensures a secure connection, suitable for automated production and efficient installation.

3. Five Solder Pads:

   This product provides five solder pads for easy connection to the circuit board, supporting more flexible installation.

4. Built-in 5.1K Resistor:

   The 5.1K resistor ensures signal stability and more reliable device connections.

5. OTG Function:

   Supports OTG (On-the-Go) functionality, enabling data exchange between devices, ideal for data transmission between USB devices.

Compliance Statement:

This product strictly adheres to international and industry certification standards, ensuring its compliance with safety and environmental regulations:

1. ISO 9001 Quality Management System Certification:

   Ensures the product meets international quality management standards during design and production.

2. REACH Certification:

   Complies with the EU chemicals registration, evaluation, authorization, and restriction regulations, ensuring the materials are safe and environmentally

friendly.

3. RoHS Certification:

   Complies with the EU Restriction of Hazardous Substances (RoHS) directive, ensuring the product is free from harmful substances and promotes user

health.

Contact Information:

- Hotline: 13310802726

- Email: mc13310802726@163.com

- Address: Dalingshan Town, Dongguan City, Guangdong Province

If you have any questions or need further information, feel free to contact us, and we will provide professional support.

TYPE C Female Connector 14PIN Clamp with Board, Five Pads, with 5.1K Resistor, OTG Function USB Interface Usage Notes:

1. Installation and Operation:

   - During installation, ensure the connector is properly aligned with the PCB pads for secure soldering. Check the cleanliness of the pads before soldering

to avoid contamination or oxidation, which could affect soldering.

   - Since this connector includes OTG functionality, make sure that the connected devices support OTG to ensure proper recognition and usage.

2. Electrical Performance:

   - This connector offers stable electrical performance and includes a 5.1K resistor to effectively control signal transmission and reduce electrical noise.

   - It supports OTG functionality, making it suitable for data exchange and peripheral connections between mobile devices like smartphones and tablets,

enhancing USB device flexibility.

3. Soldering Precautions:

   - Use appropriate temperature and soldering time during the process to avoid damaging the connector or PCB.

   - After soldering, use tools like a multimeter to check the solder joints for good contact and ensure there are no short circuits.

4. OTG Function Usage:

   - The OTG functionality allows devices to directly exchange data and connect peripherals without the need for a PC host. Ensure that both the connector

and device support OTG functionality.

   - Be cautious when connecting incompatible peripherals, as this could affect the normal operation of the device.

5. Application Scenarios:

   - Suitable for mobile devices, portable devices, and smart devices that require OTG functionality. Widely used in smartphones, tablets, cameras, external

storage devices, and more.

   - Especially suitable for achieving high-speed data transfer and peripheral connections in mobile devices.

6. Storage and Transportation:

   - Store in a dry, mild environment to avoid moisture and high temperatures that could affect connector performance.

   - During transportation, avoid heavy impacts to prevent damage to the solder joints and resistor.
