Industry certification:

USB-IF certification (USB2.0 Full Speed), RoHS 2.0 (lead content<0.1%), REACH SVHC 235 item testing qualified.

CE/FCC electromagnetic compatibility (conducted disturbance ≤ 40dB μ V, radiated disturbance ≤ 30dB μ V), UL 94 V-0 flame retardant certification (shell burning rate ≤ 100mm/min).

Industry standards:

Industrial applications comply with ISO 13849-1 (PLd), and automotive electronics can choose AEC-Q200 (-40 ℃ to 125 ℃ temperature cycling).

Quality control:

Sampling inspection for each batch: magnetic attraction test (tensile strength ≥ 3N), dynamic contact impedance test (Δ R<15% after 10000 insertions and removals), and high-temperature aging (105 ℃, 96 hours).

For more information, please contact us:

- Hotline: +86 13310802726

- Email: mc13310802726@163.com

Installation requirements:

Reflow soldering peak ≤ 255 ℃, insulation fixtures (temperature resistance ≤ 120 ℃) are required in the magnet area to avoid demagnetization; The tolerance between the positioning column and the PCB through-hole is ≤ 0.05mm.

Usage restrictions:

Non waterproof products are prohibited from coming into contact with liquids, and waterproof sealing rings are recommended to be replaced annually; When the continuous current is greater than 3A, the thickness of the PCB copper foil is ≥ 50 μ m (1.4oz).

Maintenance suggestion:

Clean the iron filings on the surface of magnets with compressed air every quarter in industrial environments; Medical equipment should be wiped with 75% ethanol, and chlorine containing disinfectants are prohibited.
