Type-C Magnetic Male Connector 5PIN Oval Shape USB Interface

Product Overview

This TYPE C magnetic 5PIN male connector features a magnetic design that ensures stable and reliable electrical connections. Its elliptical shape combined with 5PIN pins is ideal for devices requiring magnetic connections. The product supports data transfer and charging functions, offering easy plug-and-play operation, and is widely used in smart hardware, consumer electronics, and other electronic devices.


  • Description
  • Product Compliance
  • Precautions
  • Make an inquiry

    Product Description:

    This TYPE C magnetic male connector features a 5PIN interface and an oval design, equipped with a magnetic function for easy and quick connection

    and disconnection. It complies with USB interface standards and is widely used for data transmission and charging needs in electronic devices. The

    magnetic design ensures a stable connection, preventing the interface from loosening. It is suitable for smart home, consumer electronics, automotive

    electronics, and other fields.


    Key Features:

    1. Magnetic Design:

       The product features a magnetic function that allows for quick connection and disconnection, providing a stable connection and preventing loosening

    of the interface.


    2. 5PIN Interface:

       Equipped with a 5PIN interface, it supports high-speed data transmission and power connection to meet the needs of various devices.


    3. Oval Design:

       The oval design makes the connector more compact and aesthetically pleasing, suitable for various device applications and space-saving.


    4. Stability:

       The magnetic function ensures a stable connection, reducing the risk of disconnection and enhancing the reliability and safety of use.


    5. Wide Application:

       Suitable for multiple fields, including smart homes, consumer electronics, automotive electronics, and more, meeting a variety of connection needs.


    Compliance Statement:

    This product strictly adheres to international and industry certification standards, ensuring its compliance with safety and environmental regulations:

    1. ISO 9001 Quality Management System Certification:

       Ensures the product meets international quality management standards during design and production.


    2. REACH Certification:

       Complies with the EU chemicals registration, evaluation, authorization, and restriction regulations, ensuring the materials are safe and environmentally

    friendly.


    3. RoHS Certification:

       Complies with the EU Restriction of Hazardous Substances (RoHS) directive, ensuring the product is free from harmful substances and promotes user

    health.


    Contact Information:

    - Hotline: 13310802726

    - Email: mc13310802726@163.com

    - Address: Dalingshan Town, Dongguan City, Guangdong Province


    If you have any questions or need further information, feel free to contact us, and we will provide professional support.


    TYPE C Magnetic Male Connector 5PIN Oval USB Interface Usage Notes:


    1. Installation and Operation:

       - During installation, ensure that the magnetic male connector aligns smoothly with the counterpart, avoiding excessive force to prevent damaging

    the magnetic components.

       - Ensure the correct insertion direction to prevent poor contact caused by improper alignment, as the connector is magnetically designed.

       - Although the magnetic force is strong, avoid placing the connector near strong magnetic fields to prevent interference with other electronic devices.


    2. Electrical Performance:

       - This connector supports high-speed data transmission, complying with USB interface standards and is suitable for various electronic devices.

       - The connector is made with high-quality materials, ensuring low contact resistance and stable electrical performance.


    3. Magnetic Design:

       - The magnetic design provides a stable and convenient connection, ensuring long-term stability.

       - Avoid excessive force during insertion and removal to prevent damaging the magnetic components or causing unstable connections.


    4. Materials and Design:

       - Made from high-strength, durable materials, the shell has excellent wear resistance and corrosion resistance.

       - The oval shape design facilitates easy insertion and removal while enhancing connection stability and reliability.


    5. Application Scenarios:

       - Suitable for electronic devices that require magnetic connection, widely used in consumer electronics, smart home devices, audio equipment, and more.

       - Especially suitable for applications that require fast connection and disconnection.


    6. Storage and Transportation:

       - Store in a dry, cool place and avoid strong magnetic field interference.

       - During transportation, avoid heavy impacts to ensure the integrity of the magnetic components.


    For more information, please contact us:

    - Hotline: 13310802726

    - Email: mc13310802726@163.com
