Optional Board Mount

Product Description:

This product is a high-performance Apple Lighting female connector, featuring an 8PIN design with support for both vertical insert and board mount

installation. It meets the requirements of various electronic devices, offering a stable and reliable interface solution for data transmission and charging.

It is widely used in consumer electronics, smart devices, and related accessories.

Key Features:

1. Apple Lighting Interface:

   Compatible with Apple Lighting standards, supporting fast data transmission and efficient charging, suitable for all types of Apple devices.

2. 8PIN Design:

   The 8PIN structure ensures high stability and excellent electrical performance, meeting stringent usage requirements.

3. Dual Functionality:

   Supports both vertical insert and board mount installation, adaptable to various application scenarios.

4. High Reliability:

   Made with premium materials and precision craftsmanship, ensuring durability and stability during long-term use.

5. Compact Design:

   Small size allows more installation options for compact device designs.

Compliance Statement:

This product strictly adheres to international and industry certification standards, ensuring its compliance with safety and environmental regulations:

1. ISO 9001 Quality Management System Certification:

   Ensures that the product meets international quality management standards during design and production.

2. REACH Certification:

   Complies with the EU chemicals registration, evaluation, authorization, and restriction regulations, ensuring the materials are safe and environmentally

friendly.

3. RoHS Certification:

   Complies with the EU Restriction of Hazardous Substances (RoHS) directive, ensuring the product is free from harmful substances and promotes user

health.

Contact Information:

- Hotline: 13310802726

- Email: mc13310802726@163.com

- Address: Dalingshan Town, Dongguan City, Guangdong Province

If you have any questions or need further information, feel free to contact us, and we will provide professional support.

Apple Lighting Female Connector 8PIN Vertical Plug-in Compatible with Clamp Mount Usage Notes:

1. Installation and Soldering:

   - Ensure the soldering area is clean and free of oil or dust to maintain soldering quality.

   - Keep the soldering temperature within the recommended range to avoid damaging the internal structure.

   - Securely solder the contact points, particularly in clamp mode, to withstand the stress from plug-in operations.

2. Electrical Performance:

   - This product supports Lighting 8PIN interface, ideal for high-speed data transmission and charging applications.

   - Use compatible devices and cables to achieve optimal performance.

3. Insertion and Extraction:

   - Handle insertion and extraction gently to prevent damage to the socket.

   - Ensure correct alignment of the plug with the socket to avoid misalignment or damage during insertion.

   - When using clamp mode, ensure the device is securely mounted to avoid loose connections.

4. Clamp Mode Features:

   - This connector supports clamp mounting, enabling flexible designs for various devices.

   - When installed in clamp mode, ensure proper securing to prevent uneven force damaging the connector.

5. Material Properties:

   - The connector housing is made of durable materials with excellent oxidation resistance and mechanical strength.

   - Contact points are made of high-conductivity materials for stable electrical connections.

6. Cleaning and Maintenance:

   - If dust or dirt accumulates on the interface, clean it with a soft, dry cloth, avoiding corrosive cleaning agents.

   - Regularly inspect the contact points and soldering joints to ensure there is no looseness or oxidation.

7. Operating Environment:

   - This product is suitable for consumer electronics such as smartphones and tablets.

   - Avoid prolonged use in high-humidity, high-temperature, or corrosive environments to maintain stability.

8. Storage Conditions:

   - Store unused products in a dry, ventilated environment away from direct sunlight.

   - Avoid storing in extreme temperatures to prevent material aging or performance degradation.
